Larry Gibson
posted this
08 April 2025
There were 3 different levels (velocities) of M2 Ball with the 152 gr FMJ flat based bullet produced. The black tipped armor piercing ammunition also had the M2 nomenclature but I'll disregard it here. In the last 10 years or so I have chronographed and pressure tested various lots of M2 Ball and a couple lots of M1906 Ball ammunition. I have chronographed them in my M1903 and in my pressure test rifle all which have 24" barrels. The 3 different levels of M2 ammunition are readily apparent.
I measure the pressure in psi" not CUPs sometimes still referred to as "psi", particularly in older literature and manuals. The SAAMI MAP for CUP measurement was 50,000 CUP and the MAP for PSI measurement (transducer/gauge) is 60,000 psi. Thus the 50,000 of the CUP measurement is equivalent to the 60,000 psi of the transducer/gauge measurement. The MAP for M2 Ball was 47,000 CUP or about 56,500 psi as measured by transducer/gauge. TM 9-1305-200 Samll Arms Ammunition, US Army, dtd June 1961 specifies 45,000 to 50,000 psi (CUPs) for M2 Ball.
The M1906 ammunition tested produced right at 2700 fps as specified out of a M1903. It produced about 50 fps more out of the minimal chamber spec test barrel and ran right at 56,100 psi.......exactly what it was supposed to do.
In the mid '30s the supply of M1906 ammunition was running out and it was found the M1 Ball ammunition exceeded the safety fan of many training ranges, particularly National Guard training ranges. A request was made for ammunition specification comparable to M1906 ammunition be made for training use. This was the 1st level of M2 Ball ammunition performance. That specification called for 2700 fps with the 150 - 152 gr FMJ FB'd bullet. Just day before yesterday I tested a lot (DM 42) of that level of M2 Ball. It ran right at 2701 fps with 55,600 psi.
The 2nd level of performance of M2 Ball ammunition result in 1939 - 1940 when the National Guard Bureau requested a further reduction of velocity of M2 Ball resulting from the establishment of many newer training ranges (the National Guard had been mobilized pretty much completely by 1939) which did not have the safety fans to safely contain the original M2 Ball or M1906 ammunition. The request was for the M2's velocity to be reduced to 2550 - 2600 fps. This was done and I've found most of the M2 Ball tested made after the mid '50s falls into this level of performance. The velocities of numerous such lots runs from 2490 fps to 2600 fps. It appears from my testing all 3 levels of M2 Ball were produced by various arsenals up through the mid '50s with only the 3rd level produced after the adoption of the 7.62 NATO cartridge to replace the 30-06.
With the development of better powders (notably 4895 and ball powders) for use in the 30-06 cartridge in the early '40s we see the velocity specification for M2 Ball ammunition was upgraded to 2810 fps and sometimes reported as 2820 fps. This created the 3rd level of performance. I have tested numerous lots of this level also. Day before yesterday I also tested a lot of SL 52 which was loaded with 48.2 gr of extruded powder (probably 4895). It produced 2801 fps at 54,900 psi.
I have also tested a few lots of M1 Ball. Day before yesterday I also tested a lot of M1 Ball (FA 28) . The velocity ran 2638 fps at 57,000 psi.....again, just as it was supposed to do. A lot of M72 Match was also tested. It ran 2624 fps at 57,100 psi......just as it should have.
For practical shooting with M1 rifles, M1903/M1903A1s or M1903A3s I like to match the level of M2 ball performance to what the sights are regulated for. Of course if one is just shooting at one range then the regulation of the sights range doesn't matter. I shoot multiple ranges with my M1903A1 which is why I load to match the sight regulation. A 147 gr M80 bullet at 2660 - 2780 fps closely matches the regulation of the M1 Rifle rear sight. Of course, a 175 Sierra MK at 2600 – 2640 fps will also match the M1’s range settings.
The M1 Rifles sights are regulated for M1 Ball [173/174 FMJBT at 2640 fps]. The M1903/M1903A1 sights are regulated for the M1906 Ball or M2 Ball that gives 2700 fps with the 150 - 152 FMJFB bullet.
The M1903As sight are regulated for the 3rd level of performance; a 150-152 gr FMJFB bullet at 2810 fps. This is why many were frustrated with level 1 and particularly level 2 M2 Ball performance in M1903A3s.....the sight range settings just didn't correlate to impact at those ranges.
Quality M2 Bullets are almost impossible to get. In all my testing I found a great degradation of accuracy in US made M2 Ball after the late 50s, particularly that produced in the '60s and early '70s. The bullets are just of poor quality. Thus I use 7.62 M80 bullets which hold 2 moa +/- out of my M1903A1. The commercial made Hornady's have always given me the best accuracy, usually 1 1/2 moa +/-. I got a bunch of pull down M80s from Widner's about 10 years ago that hold 2 - 2 1/2 moa +/-.
I use 4895 for my loads with M80 bullets and in my M1903A1 load them to 2640 - 2650 fps which regulates the trajectory to the sight quite close out to 1000 yards. For use in my M1903A3 I load the M80 bullets to 2730 fps which then regulates the trajectory to the sight ranges to 800 yards. The use of M80 bullets may be what you'll also find to be the best option.
LMG
Concealment is not cover.........
